Seri outdoor terbaru dari Totolink. - Long Distance Transmission - Protection Design - Flexible Power Supply by Passive PoE.
CP300 is WISP CPE Solution that specially designed for long distance wireless transmission. With two internal high gain antennas and advanced radio architecture, it can make the radio signal transmission coverage more extensive with a stable wireless connection and deliver up to 300Mbps data rate. Powered by Passive PoE, CP300 simplifies the network cable deployment and is suitable for all kinds of environment with the waterproof design. Long Distance Transmission With two internal high performance antennas, CP300 can deliver up to 300Mbps wireless data rate with stable Wi-Fi connection. Placed on the roof of the building, it can excellently transfer stable signal for long distance use. Protection Design With the waterproof design, it can adapt to any poor working environment and effectively protect itself from dust, water and lightning. Flexible Power Supply by Passive PoE Powered by Power over Ethernet (PoE) technology, CP300 can not only ensure the security of structured cabling but also improves the deployment flexibility and reduce costs.
Overviews Features Design Tech Specs Download FAQs - Complies with IEEE802.11n /g/b standards on 2.4G band. - Supports PPPoE, DHCP, Static IP, PPTP and L2TP broadband functions. - Two powerful internal antennas. - Multiple APs allows user to add other two SSIDs accordingly. - 4 LED signal strength indications. - Supports 64/128 bit WEP encryption and WPA-PSK, WPA2-PSK security. - Repeater function allows more terminals to access Internet. - Supports passive PoE power supply. - Lightning protection design. - QoS can allocate bandwidth reasonably.
HARDWARE FEATURES Interface 1 *100BaseTX (Auto MDI/MDIX) LAN Port Power Supply 12V DC /1A (PoE) Button 1 *Reset Button Antenna 2 *8dBi internal antennas LED Indicators 1 *Power, 1 *LAN, 1 *WLAN, 4 *Signal Strength WIRELESS FEATURES Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3u, IEEE 802.3 RF Frequency 2.4~2.4835GHz Data Rate 802.11n: up to 300Mbps 802.11g: up to 54Mbps (dynamic) 802.11b: up to 11Mbps (dynamic) EIRP < 20dBm Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) Reception Sensitivity 270M: -64 [email protected]% PER 135M: -65 [email protected]% PER 54M: -68 [email protected]% PER 11M: -85 [email protected]% PER 6M: -88 [email protected]% PER 1M: -90 [email protected]% PER SOFTWARE FEATURES Operation Mode Gateway, Bridge, Wireless ISP Network LAN Setup, Static DHCP Setup , WAN Setup Wireless Basic Setting, Security Setting, Advanced Setting, Multiple APs, MAC Authentication, WDS, WPS, Repeater Firewall IP/Port Filtering, MAC Filtering, URL Filtering, Port Forwarding, DMZ Setting, Denial of Service Management Statistics Dynamic DNS Setting (Bridge mode doesn’t have this option) Time Zone Setting Remote Management System Log Upgrade Firmware Save/Reload Setting Administrator Setting Others - Package Contents CP300 Wireless CPE *1 PoE Box *1 Power Adapter *1 Ethernet Cable *1 Quick Installation Guide *1 Environment Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
